GX5 Hydraulic System

AgXcel’s line of diaphragm pumps are the most complete and accurate line of hydraulically driven pumps available for applying a variety of liquids including herbicides, pesticides, liquid fertilizers and hard-to-handle fluids. The GX5 pumps are available in a large flow range and this is due to fact that they are hydraulically controlled. They deliver the highest grade of reliability, rapid rate response, and require minimal maintenance. The GX5 is a positive displacement pump so for every revolution of the pump shaft will results in a specific volume of flow. Positive displacement pumps, unlike centrifugal can produce the same flow at a given speed (RPM) no matter what the discharge pressure. Thus, positive displacement pumps are constant flow machines making the GX5 one of the most accurate volume placement pumps on the market.

GX5
GX5
GX5
GX5
GX5 on JD
GX5 on JD
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 mounted with Universal Mount
GX5 on JD
GX5 on JD
GX5 on JD DB
GX5 on JD DB
GX5 on JD DB
GX5 on JD DB
GX5 used in potato planting
GX5 used in potato planting
GX5 on Gladiator
GX5 on Gladiator
The AgXcel GX5 PWM Control Valve

AgXcel's custom built hydraulic PWM valve is designed to perform even under the most demanding environments. The PWM hydraulic valve is designed for both closed center and open center systems and can be tuned for either configuration with a simple valve adjustment. Additionally, the PWM valve can also be configured for power beyond systems when valve remotes on the tractor are limited. The PWM also has a built in manual override control that you simply turn and lift the manual override to check for proper hydraulic connections a great feature for ensuring proper hydraulic flow.

AgXcel's Hyd PWM
AgXcel's Hyd PWM

Implementing vApply this season and require a pump with no pulsating and ability to operate at high pressures?

Introducing AgXcel’s Newest GX5 D45 LFP Hydraulic Solution to smoothly and accurately apply liquid with high speed planting environments that use vApply HD and or FurrowJet.

Utilizing AgXcel's proprietary PWM Hyd Valve and D45 Blue Flex pump for unmatched system performance.

·     Low Maintenance

·     3-Headed Positive Displacement Pump

·     Minimal Hydraulic Oil Usage (.5 - 3.2 GPM) for D45 in furrow setups

·     High Pressure Capabilities

·     Minimal to Zero Pulsation Allowing vApplyHD modules to maintain steady and consistent flow

·     D45 LFP Range of .5 - 11 GPM OPEN FLOW*

    D80 LFP RANGE .5 - 20 GPM OPEN FLOW*

    D120 LFP RANGE .5 - 30 GPM OPEN FLOW*

  * WITH PLUMBING, ORIFICING AND PRESSURE  GPM WILL DROP UP TO 40% OF MFG GPM

·     Blueflex Technology - Long-life Diaphragms for resistance to spraying chemicals and aggressive liquid fertilizers

NOTE: All AgXcel GX5 systems utilize the AgXcel Hyd PWM 10 GPM valve.


HEAVY DUTY & LONG LIFE
AgXcel has introduced an innovative diaphragm material called BLUEFLEX, designed by AR which marks a new era in the diaphragm pump sector. If you work in the agricultural or industrial spraying sector, this material establishes a new benchmark for diaphragm durability under the toughest working conditions. First intensive life testing was conducted at AR labs and then at AgXcel labs; followed up with extensive real-world field testing. From weed killers, fungicides, pesticides, liquid fertilizers to some of the toughest to handle liquids and aggressive chemicals, we believe that AR has come up with the best performing diaphragm material currently available in the market. The diaphragms have a special shape which was developed using proprietary technology in fluid dynamics. All AgXcel pumps can be fitted with the BLUEFLEX diaphragms, as we have the complete BLUEFLEX diaphragm range from the lowest flow pump to the highest flow pump. An additional important benefit is that each diaphragm has a date code on the liquid side of the diaphragm. This is an industry FIRST. It allows us to track and identify the production lot of the diaphragms, by year and by month. For all the above reasons, you owe it to yourself to put the BLUEFLEX diaphragms to the test. For all those especially demanding crop protection jobs, or for transferring aggressive chemicals or for disinfestation, go with the BLUEFLEX diaphragms that are a step ahead. Go beyond your expectations with BLUEFLEX.



AgXcel GX5 Hydraulic Diaphragm Pump Solution

Here are a few more features of the GX5 diaphragm pump -

  •  Have good suction lift characteristics, some are low pressure pumps with low flow rates; others are capable of higher flow rates, dependent on the effective working diameter of the diaphragm and its stroke length. They can handle sludge and slurries with a relatively high amount of grit and solid content.
  •  Suitable for discharge pressure up to 1,200 bar
  •  Have great dry running characteristics
  •  Are up to 97% efficient.
  •  Are superior in handling high viscous liquids
  •  There are no seals to ruin and it’s nearly impossible for the system to develop air lock
  •  When the GX5 is mounted on an liquid cart or pull cart, the GX5 will easily draw liquid to supply even the highest demands for liquid placement on any implement
  • Simple Installation - The GX5 pump is completely assembled at the factory to make your installation process a breeze. Optional features like bypass agitation, pressure transducer kit and optional mounting brackets.

The AgXcel GX5 PWM hydraulic system has been utilized in various application environments like 2x2 application, strip till application, side dress just to name a few. As will all AgXcel solutions, the GX5 integrates seamlessly into all major OEM controllers or can be managed with the AgXcel Auto X compact controller.
